Author:Tammy Wechat/Whatsapp:+86 18366503918 Email:yatefilter01@163.com   The structure and working principle of liquid filter bag filter Bag filter is a pressure filtration equipment. The water inlet pipe on the side of the shell flows into the filter bag. The filter bag itself is installed in the reinforced mesh basket. The liquid passes through the filter bag of the required fineness grade, and the impurity particles are intercepted by the filter bag, so as to obtain qualified filtrate. It is very convenient to change the filter bag of this machine, and there is basically no material consumption. The bag filter has the advantages of good sealing, strong flow capacity and convenient operation.   Liquid filter bag is a widely used equipment and one of the key components of the filter. Generally speaking, liquid filter bag has the following characteristics: 1. Stainless steel welding technology is usually used, and the horizontal error is less than 0.2 mm. It can be installed in the equipment to improve the sealing degree. In addition, the possibility of side leakage can be reduced, and the filter bag diameter error is less than 0.5 mm. 2. The label on the filter bag indicating the product specifications and models should be easy to replace to prevent the filter bag from being contaminated by labels and ink during use. 3. Generally speaking, the product is produced by high-speed industrial sewing machines, and there is no need to reduce the temperature of silicone oil, because this production method will not cause silicone oil pollution.   The filtrate surface of the liquid filter bag is specially singed, which not only effectively prevents the fiber from falling off and contaminating the filtrate, but also avoids excessive clogging of the filter holes by traditional rolling treatment. All raw materials are pure white, without any special bleaching and dyeing treatment, which fully meets environmental protection standards. Moreover, due to the three-dimensional filtration layer of the needle felt, when the liquid flows through the filter bag, due to the deep filtration mechanism, the particles will stay on the inner wall and deep layer of the liquid filter bag, and the capture efficiency of solid or colloidal particles is high.   The filtrate surface of the liquid filter bag adopts a special single-line treatment, which not only effectively prevents the fiber from falling off and contaminating the filtrate, but also avoids excessive clogging of the filter holes by traditional rolling treatment, shortening its service life. All raw materials are pure white, without any special bleaching treatment, which fully meets environmental protection standards. Moreover, due to the three-dimensional filtration layer of the needle felt, when the liquid flows through the filter bag, due to the deep filtration mechanism, the particles will stay on the inner wall and deep layer of the liquid filter bag, and the capture efficiency of solid or colloidal particles is high   Author:Tammy Wechat/Whatsapp:+86 18366503918 Email:yatefilter01@163.com

The latest developed diatomaceous earth filter Advantages: 1. High filtration accuracy: can reach 0.1-2 microns 2. No consumables: The filter chip is made of high-quality original diatomaceous earth through exclusive technology sintering, no need to replace, no consumption, it is an excellent choice for cost saving 3. Backwashing function: Different from traditional core and bag filters, it can be backwashed with raw liquid or water 4. Save labor costs 5. Acid and alkali resistance: Physical and chemical properties are stable, acid and alkali resistance, corrosion resistance 6. High temperature resistance: Made of high temperature sintering, it is an excellent choice for high temperature resistance 7. It can filter viscous liquids, especially in the food and beverage industry. 8. If you want to filter wine, it will be an excellent choice. When you need to add diatomaceous earth powder or activated carbon powder to the liquid, the interception effect of this filter is beyond your imagination   If you want to know more about diatomaceous earth filters, please contact me Email:tammywang977@gmail.com Wechat:+86 18366503918 Whatsapp:+86 18366503918

As the world pays more and more attention to environmental protection and industrial sustainable development, YATE recently announced the launch of an innovative PP filter bag product, which aims to help the industrial filtration field achieve green upgrades and reduce environmental pollution.   This PP filter bag is made of advanced polypropylene material and has excellent chemical stability and filtration efficiency. Compared with traditional filter materials, PP filter bags have higher wear resistance, corrosion resistance and high temperature resistance, and can operate stably for a long time in harsh industrial environments.   YATE said that the research and development of this PP filter bag is to meet the demand for efficient and environmentally friendly filter materials in the industrial filtration field. By optimizing the structure and material of the filter bag, the PP filter bag can effectively intercept pollutants such as solid particles and oil droplets, reduce the discharge of wastewater and exhaust gas, thereby protecting the environment and reducing corporate operating costs.   It is understood that PP filter bags are widely used in many industrial fields, such as chemical, electric power, pharmaceutical, food, etc. In the chemical field, PP filter bags can be used to filter various corrosive media such as acids, alkalis, and salts; in the electric power field, PP filter bags can be used for environmental protection projects such as flue gas desulfurization and dust removal; in the pharmaceutical and food fields, PP filter bags can be used to filter liquid products such as liquid medicines and beverages.   YATE said it will continue to be committed to the research and development and application of environmental protection technology, and provide more efficient and environmentally friendly solutions for the industrial filtration field. At the same time, the company also called on more companies to join the environmental protection cause and jointly promote industrial sustainable development.   The launch of this new PP filter bag marks another important breakthrough for Google YATE in the field of environmental protection technology. We look forward to this product playing a greater role in the future industrial filtration field and making greater contributions to environmental protection and sustainable development.

Electrophoretic paint treated bag filter   The electrophoretic paint bag filter is a multi-purpose filtration equipment with novel structure, small size, easy and flexible operation, energy saving, high efficiency, closed operation and strong applicability. Electrophoretic paint bag filter is a new type of filtration system. The inside of the electrophoretic paint bag filter is supported by a metal mesh basket. The liquid flows in from the inlet and flows out from the outlet after being filtered by the filter bag. The impurities are intercepted in the filter bag and can be used again after replacing the filter bag.     The electrophoretic paint bag filter is simple to operate. When using it, you only need to install the filter bag of the required fineness grade into the filter cartridge, check whether the O-ring is intact, and then tighten the ring bolt of the filter cartridge cover, and it is ready to work. After the pump is started, the pressure gauge on the filter rises slightly, and the initial pressure is about 0.05MPa. As the use time increases, the filter residue in the cylinder gradually increases. When the pressure reaches 0.4MPa, the machine should be stopped and the cylinder cover opened to check the residue left in the filter bag. situation, the filter bag can be replaced and continued to be used (the filter bag can generally be reused after cleaning). It is generally appropriate to adjust the filter pressure to 0.1-0.3MPa, which can be adjusted through the return pipeline or the return valve on the pump. If the filter pressure is too high, it will damage the filter bag and the protective net, so special attention is required.   The outer shell of the electrophoretic paint bag filter is generally made of stainless steel. Inside, filter bags of different materials can be selected according to media characteristics, temperature, and filtration accuracy.   Features   1. The probability of side leakage of the filter bag is small, which effectively ensures the filtration quality. 2. Bag filter can carry greater working pressure, has small pressure loss, low operating costs and obvious energy saving effect. 3. The filtration accuracy of filter bags continues to improve, reaching 0.5μm. 4. Bag filter has large processing capacity, small volume and large dirt holding capacity. 5. Based on the working principle and structure of the bag filter system, it is convenient and quick to replace the filter bag, and the filter does not need to be cleaned, saving labor and time. 6. The filter bag can be used repeatedly after cleaning, saving costs. 7. Bag filter has a wide range of applications, flexible use and various installation methods.   Work flow and precautions for electrophoretic paint bag filters   From the operating principle, the electrophoretic paint bag filter is a pressure filtration equipment. Its main components include filter cylinder, filter cylinder cover and quick-opening mechanism, stainless steel filter bag reinforcement mesh, etc.   The electrophoretic paint bag filter is easy to operate. When using it, you only need to install the filter bag of the required fineness grade in the filter cartridge, check whether the O-type sealing ring is intact, and then tighten the ring bolt of the filter cartridge cover, and it can be put into operation. After the pump is started, the pressure gauge on the filter rises slightly. The initial pressure is about 0.05MPa. As the use time extends, the filter residue in the cylinder gradually increases. When the pressure reaches   When 0.2MPa, the machine should be stopped and the simple cover opened to check the residue left in the filter bag of the electrophoretic paint bag filter. The filter bag can be replaced and continued to be used (the filter bag can generally be reused after cleaning).   Application fields of electrophoretic paint bag filter   Main uses: paint, beer, vegetable oil, medicine, chemicals, petroleum products, textile chemicals, photosensitive chemicals, electroplating solution, milk, mineral water, hot solvent, latex, industrial water, sugar water, resin, ink, industrial wastewater, fruit juice , edible oil, wax, etc.

Bag filters are a relatively common type of filter that can be used in many industries and can have different effects in each industry. So what role can bag filters play in the ink industry? The function of bag filter The equipment structure of the bag filter is relatively simple and can withstand extremely high filtration pressure and water hammer pressure impact. It consists of three parts: filter cartridge, filter screen and filter bag, and has a relatively compact structure. The liquid that needs to be filtered will enter through the inlet of the filter. After flowing into the filter bag, it will be intercepted by the filter bag and finally flow out from the outlet of the filter. The inlet and outlet design of the bag filter generally adopts a side-in and bottom-out working method for easy cleaning. Application of bag filter in ink industry 1. Filtration of raw materials such as resin 2. Remove fibers and gel from paint; 3. Filter the solvent; 4. Filter particles whose grinding fineness does not meet the standard. 5. Remove particulate impurities after mixing reaction 6. Remove the agglomeration of gum paint; 7. Remove oil from paint Bag filter performance characteristics 1. The probability of side leakage of the filter bag is small, which can ensure the quality of filtration; 2. The bag filter can withstand greater working pressure during operation, has small pressure loss, low operating costs, and obvious energy-saving effects; 3. The filtration accuracy of filter bags is constantly improving, and it can now reach 0.5um; 4. The bag filter has a large processing capacity, small volume, and large dirt holding capacity. 5. The bag filter is based on the working principle and structure of the filtration system, which makes it more convenient to replace the filter bag, while the mesh filter does not need to be cleaned, which can save labor and time; 6. The filter bag of the filter can be used repeatedly after cleaning, saving costs; 7. Bag filters have a wide range of uses, are convenient and flexible to use, and can be installed in various ways. Bag filter operation precautions The operation of the bag filter is relatively simple. When using it, you only need to install the filter bag of the required fineness grade into the filter cartridge to check whether the O-type sealing ring is intact, and then tighten the ring bolt of the filter cartridge cover before putting it into use. Used at work. After the pump is started, the pressure gauge on the filter will rise slightly, and the initial pressure is about 0.05mpa. As the use time increases, the filter residue in the cylinder will gradually increase. When the pressure of the filter reaches 0.4mpa, the machine should be stopped and the simple cover opened.   Check the residue left in the filter bag and continue using it after replacing the filter bag. The pressure of the filter is generally 0.1-0.3mpa would be more appropriate, and can be adjusted through the return pipeline or the return valve on the pump. The filtered pressure exceeds.When it is high, it will damage the filter bag and protective net, so special attention is required.

Sunflower oil filtration case   Sunflower seed oil is a vegetable oil extracted from sunflower seed kernels. The content of vitamin E in the oil exceeds that of most vegetable oils. Eating sunflower seed oil is beneficial to human health and is favored by consumers in the market. So today Please ask the engineer of Shandong Yate Filtration Material Co., Ltd. to introduce the sunflower seed oil filtration process in detail. Let’s take a look together.   Pretreatment - grinding - leaching - degreasing - sedimentation - filtration - deodorization     You can clearly see that there are four parts in the picture above: bag filter, core filter, sanitary electric centrifugal pump, and trolley.   1.Bag Filter: The bag filter adopts simple and fast switch operation to minimize downtime; the filters adopt the industry-recognized lifting ring quick-opening and rocker lifting ring quick-opening designs, which are safe and reliable; the side-entry conflict design ensures that the liquid can be completely Discharge, the tangent position of the height can be reduced; it is more convenient to install pipelines.   2.Cartridge Filter: The pleated filter element filter is made of SUS316L or SUS304 stainless steel. It uses the pleated filter element as the filter element. It can filter gas, liquid, particles and bacteria above 0.1 micron, with high filtration precision, fast filtration speed, less adsorption, and no media shedding. It has the advantages of no leakage, acid and alkali resistance, corrosion resistance, easy cleaning, and rice flushing function. It is an ideal filtration equipment for biomedical pure water, food and beverage, biochemical water treatment and other industries.   3.Pump:  Pumps are divided into two forms, namely pneumatic diaphragm pumps and electric centrifugal pumps. The differences are as follows: Pneumatic diaphragm pump: suitable for viscous liquids. If the liquid to be filtered is as viscous as honey, a pneumatic diaphragm pump is needed. A pneumatic diaphragm pump needs to be used with an air compressor. The air compressor is a very common small device that you can buy anywhere. Electric centrifugal pump: suitable for liquids without viscosity like milk. If you want to filter high-quality wine, you need to use an explosion-proof electric centrifugal pump.   4. About the trolley The size of the trolley is customizable and will adjust to the size of the device, making it easier to move the filters while you are in use. If you don’t need a stroller, that’s fine too

Xanthan Gum Final Filtration System Case       Xanthan gum is an important industrial raw material, widely used in petroleum, chemical industry, food, medicine and other fields   Xanthan gum needs to be extracted with ethanol in large-scale industrial production. The extract (used ethanol) needs to be distilled to increase the concentration and purity before being reused. However, some xanthan gum is dissolved in the extract. During the distillation process, xanthan gum The glue will precipitate into a solid state and adhere to the distillation tray. A small amount of adhesion will reduce the distillation efficiency and increase energy consumption. A large amount of adhesion will directly cause the distillation device to be unable to work and halt production. The existing technology does not directly send the extract liquid to the distillation device for distillation. It stops working for about a week, and the distillation system is opened to clean the trays. After cleaning, the trays can be distilled again. This not only wastes manpower and material resources, but also hinders the continuous progress of production. Large-scale In order to ensure continuous production, manufacturers can only equip two sets of distillation systems. While cleaning one set, they turn on the other to achieve continuous production, which generates a lot of waste.   The final xanthan gum liquid is in a very thick state, with impurity particles of varying sizes and containing a large amount of floc. A filter layer system is required to complete the final filtration work.   In order to improve production efficiency and reduce labor costs. Yate launches a fully automatic external scraper filter + bag parallel filter system for you. With a filtration precision of 200 microns, you can perfectly complete the filtration work and get the liquid you ultimately need.

Background:   In the honey processing industry, there are three honey production processes: concentration technology, purification technology, and resin adsorption and removal technology. Among them, concentration technology is the most common and most mature technology in honey production lines. In recent years, honey processing techniques in various countries have been continuously innovated, and the technological processes have gradually become consistent. However, the choice of honey processing technology still requires appropriate processing based on the characteristics of different honeys, especially considering that high temperature will affect the active ingredients in honey. Nowadays, many advanced and high-end honey manufacturers no longer use high temperature and concentration processes. Honey production companies More leaning towards cold filtration technology. It can be seen that the honey filtration process is a very critical link in the entire honey production process.   Challenge:   According to the reality of beekeeping, bulk separated honey from bee farms often contains impurities such as wax shavings, larvae, and bee corpses. It is very unsightly in appearance and gives people a sense that the product quality is not up to standard, thus affecting the quality of the product. Its seller and product positioning. Therefore, these impurities in raw honey must be filtered out, but during the honey filtration process, the beneficial ingredients in honey - pollen - will also be filtered out. Therefore, how to choose a suitable honey filter and honey filter is an issue that must be considered when designing a honey production line. Production process: It can be seen from the honey production process that the honey filter runs through the entire honey production line. From the initial coarse filtration to the later precision filtration and the final security filtration before the finished tank.   Solution:   The first coarse filtering of honey: Purpose of filtration: to remove impurities and a small amount of larger crystals. Honey is roughly filtered to remove dead bees, larvae, wax residue and other impurities in the honey. Honey filter selection: If it is a large-volume honey production line, it is recommended to use Yate's fully automatic internal scraper self-cleaning filter.   Advantage: 1. It can achieve a production capacity of 2000-5000 kilograms per hour to achieve efficient production. 2. The filter in the honey filter can be easily disassembled and cleaned, allowing the factory to select the appropriate filter screen size according to different honey varieties. 3. This honey filtering equipment can automatically scrape off impurities on the surface of the honey filter to prevent clogging of the filter, and can also automatically discharge sewage according to time. 4. Reduces manual operation and maintenance costs. 5. Reduces the cost of consumables and waste disposal of filter bags or filters. 6. The filter is made of stainless steel 316, with food-grade polishing on the surface and can be cleaned by CIP.   Fully automatic self-cleaning filter:     The second honey filtering process:   Purpose of filtration: to remove remaining impurities and a small amount of larger crystals in honey. Honey filter selection: Due to precision filtration, Zhuopin Technology engineers recommend using a bag filter equipped with a nylon screen filter bag.   Bag filter:     The third security filtration of finished honey:   Purpose of filtration: The last filtration is to prevent unfiltered impurities and crystals from the previous stage and ensure the quality of the finished honey.   Honey filter selection: Security Filtration also recommends using Art filter material bag filters equipped with nylon screen filter bags with stable filtration efficiency.   Nylon filter bag:     For 12 years, Shandong Yate Filtration Materials' professional technical team has been pursuing improving product quality, increasing productivity, reducing production costs and waste treatment costs, and reducing manual operations in dangerous sections. Relying on Yate's filter material engineers' many years of rich experience in on-site use of filter equipment, Yate Filtration Materials is committed to providing overall solutions for filtration and separation in the production processes of petrochemical, fine chemical, food and beverage industries. If you want to know the detailed technical information and operation matters in the honey filtration process, please contact Shandong Yate Filtration Material Engineer: WhatsApp: +86 18366503918 Email: yatefilter01@163.com
